Description
FEATURES
8” driver made from genuine DuPont™ Kevlar® fiber
1″ Tetoron® soft dome pivoting tweeter
Baffle-mounted mid & high-frequency acoustic compensation / EQ switches
Frequency: 35Hz – 21kHz ± 3 dB
Sensitivity: 91 dB 1 watt / 1 meter
Impedance: 8 ohms
Power Handling: 60 w to 120 max
Load-balancing toggle mounting system
High-temperature Polyimide voice coils
Magnetic, frameless, microperforated grille (may be custom painted)
Acoustically transparent scrim cloth grille backing hides speaker components from view
| SPECS DESCRIPTION | SPECS |
| System Design | In ceiling |
| Enclosure | Open back |
| Woofer | (1) 8″ kevlar cone |
| Tweeter | (1) 1″ pivoting Tetoron soft dome |
| Recommended Amp Power | 60-120 W |
| Frequency Response | 35 Hz – 21 kHz +- 3dB |
| Impedance | 8 ohms |
| Sensitivity (db 1 watt/1 meter) | 91 |
| Dimensions | 9-7/8″ dia. |
| Hole Cut Out | 8-5/8″ x 4″ d |
| Standard Finish | White frameless magnetic grille |
