THE FUSION

SW10P 300

The Fusion SW10P 300 watt powered subwoofer has distinct advantages over other mainstream small format subwoofers. Its speed and dynamics, coupled with very low harmonic distortion, place it among the very best in its class. Sonically, it’s a near perfect “blend” for our custom Fusion LCR, providing unparalleled performance with regard to fill and tonality. In addition, the Fusion SW10P exhibits outstanding performance when pairing with small to medium format speakers.

FEATURES

Lower distortion due to very high magnetic flux, shorting rings and excellent mass balance. X max, peak to peak, is nearly 1″. In plain English, you can crank it without compromising its sound quality. The near complete lack of 2nd harmonic distortion (masking overtones) makes the SLS sound as if it goes significantly lower than its measured response to 35 Hz
Very high attack provides seamless coupling to bar speakers where standard subs do not “fill” properly. This is especially noticeable in male voices, dialogue, and impact relating to explosions and dynamic events
True 300 W rms amp has a specially built EQ circuit to extend bass down below 28 Hz. Variable phase from 0-180 provides precise room tuning
Ultra-rigid, 13 ply, Baltic Birch front baffle has extremely high Young’s Modulus (stiffness) and doesn’t flex. This is extremely important for woofer coupling to cabinet and increases far field efficiency by nearly 3 dB
Proprietary, hand built, butt joint cabinet, using high strength industrial glue optimizes edge to surface coupling and vibration transfer making it almost inert at low frequencies. In plain language, most subwoofer cabinets are V grooved and flex, ours does not

Preferred Settings:

Placement in front of the listener: Mid-wall – We generally recommend a number of trials before establishing best location
Level: ½ way or 12 o’clock
Frequency Control (cut off): 10 o’clock
Preferred Phase setting: Can only be achieved by listening over a wide area of seating positions. Start at “0” and gradually move the dial clockwise until integration with associated bar speaker is optimized
Break-in: Approximately 30 hours at moderate levels

Preferred Settings:

Placement in front of listener: Mid-wall – We generally recommend a number of trials before establishing best location
Level: ½ way or 12 o’clock
Frequency Control (cut off): 10 o’clock
Preferred Phase setting: Can only be achieved by listening over a wide area of seating positions. Start at “0” and gradually move the dial clockwise until integration with associated bar speaker is optimized
Break-in: Approximately 30 hours at moderate levels

Fusion SW10P / 300 Specs

System Design	Sealed LF 10” Subwoofer- Ultra Low Distortion
Bass Unit	10″ cast frame rare earth long throw driver
Response	28 Hz – 120 Hz
Amplifier	300 W RMS
Max SPL / Sensitivity	115 / 92 dB @ 1w
Room Size	Up to 200 sq ft.
Finish	High Gloss Black (standard)
Dimensions	12″ h x 13.5″ d x 12″ w
Shipping / Product Weight	19 lbs / 22 lbs
